New Low stock

Digital Clamp Meter AC/DC Voltage Resistance Frequency DM6266 with Battery

SKU: V563-CK29865

Key Highlights:

• Multifunction testing: measures AC/DC voltage, AC current, resistance, frequency and temperature
• Safety feature: fully functional overload protection guards against damage
• Easy operation: portable, one-hand design makes testing simple and convenient
• Enhanced accuracy: double-insulated clamp with anti-jamming for reliable readings
• Ready to use: batteries included so you can start testing right away

  • Ships from AUSTRALIA

Price
$39.95
Shipping Estimate
Out of stock
Description

Digital Clamp Meter AC/DC Voltage Resistance Frequency DM6266 - Batteries Incl.

DM6266 multifunction digital clamp meter

  • Fully functional overload protection
  • Measures AC current, AC voltage, DC voltage, resistance, frequency, Temperature
  • Portable design, one-hand operation, easy to use
  • Clamp with a double insulation protection, enhanced anti-jamming
  • Non-contact measurement, to improve the measurement safety.

Specifications:

V563-CK29865V563-CK29865
  • DC voltage: 1000V ± (0.8% + 2)
  • AC voltage: 750V ± (1.2% + 4)
  • AC current: 200A / 1000A ± (2.5% / 3.0% + 5)
  • Resistance: 200Ω / 20kΩ ± (1.0% + 1)
  • Continuity alarm
  • Low voltage display
  • Data Hold
  • Input impedance: 10MΩ
  • Sampling frequency: 3 times / s
  • AC Frequency: (40-400) Hz
  • Manual range
  • Maximum display: 1999
  • Jaw opening: 50mm
  • Power: 9V (6F22) Battery x 1
  • Colors: body - dark gray
Shipping information

Item will be shipped within 1-3 working days from AUSTRALIA with most orders deliver within 7-10 working days Australia wide.

For Delivery Time Frame and More Info Click Here

14 Days Returns

Purchase with peace of mind knowing item can be returned within 14 days of delivery.

Full Details Click Here

Have a question?
Digital Clamp Meter AC/DC Voltage Resistance Frequency DM6266 with Battery

Digital Clamp Meter AC/DC Voltage Resistance Frequency DM6266 with Battery

Price
$39.95

Product information

Digital Clamp Meter AC/DC Voltage Resistance Frequency DM6266 - Batteries Incl.

DM6266 multifunction digital clamp meter

  • Fully functional overload protection
  • Measures AC current, AC voltage, DC voltage, resistance, frequency, Temperature
  • Portable design, one-hand operation, easy to use
  • Clamp with a double insulation protection, enhanced anti-jamming
  • Non-contact measurement, to improve the measurement safety.

Specifications:

V563-CK29865V563-CK29865
  • DC voltage: 1000V ± (0.8% + 2)
  • AC voltage: 750V ± (1.2% + 4)
  • AC current: 200A / 1000A ± (2.5% / 3.0% + 5)
  • Resistance: 200Ω / 20kΩ ± (1.0% + 1)
  • Continuity alarm
  • Low voltage display
  • Data Hold
  • Input impedance: 10MΩ
  • Sampling frequency: 3 times / s
  • AC Frequency: (40-400) Hz
  • Manual range
  • Maximum display: 1999
  • Jaw opening: 50mm
  • Power: 9V (6F22) Battery x 1
  • Colors: body - dark gray
